Regular price $6,595.00 Sale

Lincoln Electric Outback 185 Engine Driven Welder - K2706-2

The compact Outback® 185 is easy to start with all engine controls on the front of the machine, and it’s easy to use for welding. Use the AC generator power for a variety of applications described below with the large 6.8 gallon (25.7 liter) fuel tank

Features

  • All Engine Controls on Front Control Panel
  • 1-1/4 in. (32 mm) Diameter Rugged Tube Frame
  • 6.8 Gallon (25.7 Liter) Fuel Tank
  • Weld with up to 5/32 in. (4 mm) Stick Electrode
  • Up to 185 amps of DC output for many applications
  • 5,700 Watts Peak AC Generator Power (5,200 Watts Continuous).

    Outback 185 Technical Specifications

    Duty Cycle: 100 Amps, 25 Volts @ 100%  / 150 Amps, 25 Volts @ 20%
    Welding Output: 185 Amp DC, Max. 80V OCV
    Generator Output: 5700W Peak, 5200W Continuous 60Hz AC Power
    240V Receptacle: 21.6A
    120V Receptacles: Two 120V Receptacles, 40A Total

    Kohler Engine:
    CH440 Gasoline

    14 HP @ 3600 RPM, 429 cc
    Electric Start
    Fuel: 6.8 Gals (25.7 liters) Oil: 1.2 Qts (1.1 liters)


    Download Tech Sheet
