Lincoln CROMOCORD KV5HR E8018-B2 H4R Stick Electrodes

Lincoln Electric CROMOCORD KV5HR

AWS: E8018-B2 H4R

Low alloy stick electrode designed to produce a 1% nickel deposit

CROMOCORD KV5HR is a low alloy steel stick electrode manufactured by Lincoln Electric OERLIKON. It is designed to provide excellent tensile strength at high temperatures and is approved for use up to +570°C. The electrode offers excellent operability in all welding positions, with the exception of vertical down , and maintains a very low diffusible hydrogen level (HD < 4ml/100g).

Features

• Excellent tensile strength at high temperature, approved up to +570°C.
• Very low diffusible hydrogen (HD<4ml/100g).
• Excellent operability in all position welding except downhill.

Specifications

• Low Alloy Steel Stick Electrode
• Current Type: DC+
• Welding Positions: All positions, except vertical down
• Preheat and Interpass Temperature: 160-190°C
• Typical Chemical Composition (Weight %): C 0.08, Mn 0.75, Si 0.25, P ≤0.01, S ≤0.01, Cr 1.25, Mo 0.5.
