Lincoln Electric Ranger 225 Engine Driven Welder (KOHLER®)
eLincoln Electric Ranger 225 Engine Driven Welder
Totally Enclosed Case
Versatile DC Welding
10,500 Watts Peak Single-Phase AC Generator Power
23 HP Kohler® Gasoline Engine
ARM YOURSELF WITH THE RIGHT WELDER
The Ranger® 225 is a multi-process, engine-driven welder designed for a variety of processes – stick, TIG, MIG or flux cored. Whatever the process or application, arm yourself to get the job done and get it done right the first time.
• Totally enclosed case protects the engine and limits noise • Smooth DC welding output • 10,500 Watts AC generator power
Totally Enclosed Case • Engine is fully protected. • 3 service access doors. • Low noise – 76.4 dBA sound level at 23 ft. (7 m). 100.7 dB sound power (Lwa) at rated output.
Versatile DC Welding • Smooth DC welding output for a broad range of stick electrode types. • MIG, flux-cored and TIG capable (with optional equipment). 10,500 Watts Peak Single-Phase AC Generator Power • Peak for motor starting. • 9,000 watts continuous power for generator, plasma cutter or inverter welder. • Lights, grinder, power tools.
23 HP Kohler® Gasoline Engine • 2 cylinder, 4 cycle overhead valve air-cooled design. • Oil drain extension for easy oil changes. • 12 gallon tank for extended run times. • Only 1.5 gallons/hour at 210 amps DC, 25V, 100% duty cycle. Visual fuel level gauge on both sides of unit.
Rugged Reliability • Welding and AC generator outputs rated at 104ºF (40ºC).
