Thermal Dynamics TD CUTMASTER 30+ Plasma Cutting System
Cut up to 3/8", Sever up to 5/8"
Cutmaster 30+ is the perfect combination of power and portability for hand-held plasma cutting machine. Plus means more, so we’ve added a user-friendly 4.3 in. TFT LCD screen and upgraded features that give you even more control and flexibility to master any cut up to 10 mm (3/8 in.). Together with the SL60 1Torch, it all adds up to the total plasma cutting package.
Tackles Cuts in any Terrain with a Compact Design and Industrial Strength Housing
- Pierce and cut capacity of 3/8 in. and a maximum edge cut capacity of 5/8 in.
- 40% duty cycle at 30 A and 100% duty cycle at 20 A
- Runs on both 110 and 240 V input with auto-voltage detection
- Lightweight design with three handles for easy transportation
- Durable, weather-protected IP23S housing
Dominate any Plasma Cutting Job with Built-In Functionality and Flexibility
- Switch from normal plate to grate cutting mode to extend consumable life when working with expanded metal
- Equipped with SL60TM 1Torch® and a full range of consumables for both shielded and unshielded cutting and gouging
Mastering Cuts is Simple with the User Friendly TFT LCD Display
- Bright 4.3 in. screen is optimal for displaying settings and making adjustments
- Adjustable 2T/4T trigger lock to achieve long cuts by hand or with MechPak
- Automatic air pressure recognition and purging for proper cutting pressure and extended consumable life
- Comes standard with long-lasting Cutmaster Black Series electrodes
| Specifications | |
|---|---|
| Recommended Generator | 4.5 kW |
| Input Ratings | 110 – 240 VAC, 1 ph, 50/60 Hz |
| Duty Cycle | 30 A @ 40 % duty cycle 20 A @ 100 % duty cycle |
| Operating Temperature | -10 – 50 °C ( 14 – 122 °F ) |
| Gas Requirements | Compressed Air |
| Gas Pressure | 6.2–8.6 bar ( 90–125 psi ) |
| Gas Flow | 80–150 l/min ( 170–350 cfh ) |
| Severs Manual | 16 mm ( 5/8 in. ) |
| Pierces | Up to 10 mm ( 3/8 in. ) |
| Enclosure Class | IP23S |
| Dimensions, L x W x H | 465 x 200 x 315 mm ( 18.3 x 7.9 x 12.4 in. ) |
| Weight | 11 kg ( 24.25 lbs ) |
| Recommended Cut | Up to 10 mm ( 3/8 in. ) |
Download Tech Sheet Link To SL60 Torch Consumables
What's Included
- Cutmaster 30+ Plasma System (30 Amp)
- SL60 Torch, 75 Deg Head, 10 ft. Lead
- Ground Lead w/ Quick Disconnect
- 1/4"NPT Fitting
- 230V-120V Power Adapter
